The three phase input–three phase output online UPS is engineered for high-capacity and critical power applications. It ensures uninterrupted, clean, and balanced power supply for industrial processes, infrastructure systems, and large commercial facilities.
ARM PRO - 33
Online UPS
Product Overview
Key Features
Online Double Conversion UPS
Three Phase Input – Three Phase Output
Pure Sinewave Output
Wide Input Voltage Range
High Input Power Factor (≥ 0.95)
Solid State Static Bypass
High Overload Handling Capability
LCD Display with Detailed System Monitoring
Forced Air Cooling System
Suitable for Data Centers & Industrial Loads
Technical Specifications
Phase Configuration
Three Phase Input – Three Phase Output
Rating
10, 20, 30, 40, 50, 75, 100, 140, 170, 200Kva
Nominal Input Voltage
415VAC
Input Power Factor
≥ 0.95
Nominal Output Voltage
415VAC
Output Frequency
50Hz
Output Waveform
Pure Sinewave
Crest Factor
Better than 3:1
THD (Linear Load)
≤ 2%
THD (Non-linear Load)
≤ 5%
Dynamic Response
±2
AC to AC Efficiency
Up to 85 / Up to 88%
Overload Capacity (Mains)
125% for 10 min, 150% for 30 sec
Automatic Bypass
Solid State Static Bypass
Operating Temperature
0 to 55°C
Humidity
20–90% RH
Acoustic Noise
<60dB
EMI / EMC Standard
IEC 62040
Enclosure Protection
IP20
Cooling Method
Forced Air
LED Indications
Mains On, Inverter On, Load On, Bypass, Overload, Over Voltage, Battery Low, DC Over, DC Under, Over Temperature
LCD Display Parameters
Input Voltage, Input Frequency, Output Voltage, Output Frequency, Output Load %, Battery Voltage, Battery Current, Fault Messages, Log File
Communication Interface
RS-232
Battery Voltage (10,20 KVA)
240VDC
Battery Voltage (30,40,50,75) KVA
324VDC
Battery Voltage (100, 140) KVA
360VDC
Battert Voltage (170, 200) KVA
408VDC
Input Phase Type
Three Phase + Neutral
